INFORMATION DETAILS
ID: 13664274
|
Year: 2017
|
Make: Stealth
|
Model: SLLEFW510SA (Flat Top Wedge)
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: N/A |
| Suspension: | 3500# or 5200# Lippert Torsion Axle/s; Brake Axles w/ Breakaway Switch on TA; Wide Track Axles on 7x (No Int. Wheel Wells) |
| Wheels: | Silver Powder-Coated Modular Wheels w/ Chrome Center Caps |
| GVWR: | 2990 |
| Axle(s): | 1 |
| Height: | 60 |
| Fenders: | ATP |
| Coupler: | 2 |
| Electrical: | (2) 12 Volt LED Dome Light w/Switch (1 on 4 & 5x Models); LED Clearance and Strip Tail Lights; 7-Way Electrical Plug (4-Way on SA) |
| Hitch: | Bumper |
SELLER DESCRIPTION
|
Standard Features
|
-
Tube Steel Main Frame
-
16" O/C 2 x 3 Tube Floor Crossmembers on 4,5,6, & 7wides
-
16" O/C 2 x 5 Tube Floor Crossmembers on 8.5wides
-
16" O/C Tube Steel Wall Posts
-
24" O/C Tube Steel Roof Bows
-
Triple Tube A-Frame on 20' & Above
-
3500# or 5200# Lippert Torsion Axle/s
-
Brake Axles w/ Breakaway Switch on TA
-
Wide Track Axles on 7x (No Int. Wheel Wells)
-
ST205/75R15 LRC or ST22575R15 LRD Radial Tires
-
Silver Powder-Coated Modular Wheels w/ Chrome Center Caps
-
2-5/16" Coupler - TA
-
2" Coupler - SA
-
7-Way Electrical Plug (4-Way on SA)
-
Painted Tongue & Rear Sill (Ramp Door)
-
.030 Exterior Aluminum Screwless
-
Painted Aluminum Rear Header/Corner Posts
-
ATP Fenders
-
24" Tall ATP Stoneguard
-
Brite Anodized Front Corners
-
Seamless Aluminum Flat Top Roof
-
3" Heavy Duty Extruded Bottom Trim
-
Framed for Roof Vent
-
(1) Pair Plastic Flo-Thru Vents
-
24" Flat Top Wedge on 5' & 6'wide
-
30" Flat Top Wedge on 7'wide
-
36" Flat Top Wedge on 8.5'wide
-
No Side Door on 5 Wide Models
-
32" Aluminum Frame Side Door on 6 Wide Models
-
36" Aluminum Frame Side Door on 7 Wide Models
-
48" Aluminum Frame Side Door w/ Step Well on 8 Wide Models
-
Framed for RV Flush Lock
-
Side Door Pull-Handle
-
Stainless Steel Door Hardware
-
Ramp Rear Door w/Flap
-
White Vinyl Above Roof Bows
-
3/4" Drymax Floor
-
3/8" Drymax Walls
-
Beavertail on 8.5x20 and Above
-
(4) 5000# Recessed D-Rings on 8.5x20 and Above
-
(2) 12 Volt LED Dome Light w/Switch (1 on 4 & 5x Models)
-
LED Clearance and Strip Tail Lights
-
DOT Approved Safety Equipment
-
6" Barrier Tape
-
Limited 5 Year Structural Warranty
|
