STAINLESS STEEL SIDES AND CHAIN

THE PL88C OPEN BARREL MAIN APRON PINTLE CHAIN @ 29,900# PER STRAND STAYS FLEXIBLE. 2'' X 1'' X 3/16'' FORMED APRON CHANNELS ARE USED FOR THE APRON CROSS BARS. THE FLOOR IS 1/2'' THICK VIRGIN GRADE SOLID POLY. A STAINLESS STEEL CENTER BETWEEN APRONS THAT IS FORMED TO ELIMINATE ANY FEED BUILD-UP FOR A COMPLETE CLEAN OUT.

APRON TENSION ADJUSTMENT

APRON TENSION ADJUSTMENT IS MADE BY TIGHTENING THE 4 SPRING LOADED TIGHTENER BOLTS ON THE FRONT OF THE BOX. THE SPRING LOADED TIGHTENERS MAINTAIN TENSION ON THE APRON DURING START UP AND OPERATION.

AIR GATE DELAY

THE STANDARD AIR GATE DELAY FOR THE TOP PIVOT DOOR ALLOWS YOU TO CLEAN THE BOX OUT COMPLETELY WITHOUT MATERIAL HANGING UP. BARN DOORS WITH AIR CLOSURE ARE OPTIONAL.

DUAL HYDRAULIC MOTORS

THE ''TOP DOG'' FEATURES 1'' STEEL LINES TO THE BACK OF THE BOX AND DUAL HYDRAULIC MOTORS.

DUAL MOTORS AND BEARINGS

THE MOTORS EVENLY DRIVE EACH FINAL DRIVE SYSTEM FOR MORE POWER AND LESS SHAFT STRESS THAN A SINGLE MOTOR SYSTEM ON A 36' TRAILER. THE DRIVE SHFT FEATURES MD NYLON REVERSIBLE STYLE BEARINGS.

CUSTOM FARM NAME

CUSTOM FARM NAME-NO CHARGE

PANELS ABOVE THE FRONT AND REAR WHEELS

PANELS ABOVE THE FRONT AND REAR WHEELS ACT AS A CHAIN SLIDE FOR THE MAIN APRON AND PROTECT MUD AND DEBRIS FROM GETTING TO THE APRON CHAIN.

HIGH QUALITY STEEL MAIN FRAME

THE MAIN FRAME IS MADE OF HIGH QUALITY STRUCTURAL STEEL 10'' I-BEAMS FOR THE REAR AND COMPRESSED DOWN TO 5.13'' IN THE FRONT WITH FULL LENGTH FRONT GUSSETS. NEW 25,000# SPRING AXLE'S W/HEAVY DUTY SPINDLES ARE STANDARD. AN AIR RIDE SUSPENSION SYSTEM IS OPTIONAL.

ROLL BACK TARP AND FRONT WINDOW

OPTIONAL ROLL BACK TARP. LARGE 17''X28'' FRONT WINDOW FOR VIEWING WHEN UNLOADING.

IDLER APRON SHAFT

THE IDLER APRON SHAFT ASSEMBLY FEATURES 6 TOOTH MACHINED STEEL SPROCKETS WITH BRONZE IDLER BUSHINGS.
